Design
LED indicators: Link, Power, Activity
Rack mounting: Yes
Product colour: Black
Power
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power supply included: Yes
Power protection features: Over voltage
Power source: AC
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 70 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Width: 180 mm
Weight: 1.54 kg
Depth: 44 mm
Height: 280 mm
Network
Ethernet LAN data rates: 10,100,1000 Mbit/s
Cable types supported: Cat3, Cat5, Cat5e, Cat4, Cat6
Networking standards: IEEE 802.3x, IEEE 802.3u, IEEE 802.3i, IEEE 802.3, IEEE 802.3ab
Copper ethernet cabling technology: 1000BASE-TX, 10BASE-TX, 100BASE-TX
VLAN support: No
10G support: No
Performance
Mean time between failures (MTBF): 100000 h
Fanless: Yes
Packaging data
Package height: 370 mm
Package width: 230 mm
Package depth: 80 mm
Packaging content
Manual: Yes
Rack mount kit: Yes
Cables included: AC
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 24
Data transmission
Jumbo frames: 15000
Switching capacity: 48 Gbit/s
Forwarding rate: 35.7 Mpps
MAC address table: 8000 entries
Store-and-forward: Yes
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
