Design
Component for: PC/Server
Product colour: Green, Black
Chipset: Realtek RTL8125B
LED indicators: Yes
Internal: Yes
Country of origin: China
Power
Output voltage: 5 - 12 V
Weight & dimensions
Weight: 100 g
Width: 70 mm
Depth: 20 mm
Height: 108 mm
Network
Networking standards: IEEE 802.3bz, IEEE 802.3az, IEEE 802.1Qav, IEEE 802.1Q, IEEE 802.1ad, IEEE 1588v2, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u
Wake-on-LAN ready: Yes
Ethernet LAN data rates: 2500, 1000 Mbit/s, 100
Ethernet interface type: Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet
Maximum data transfer rate: 10000 Mbit/s
Ethernet LAN: Yes
Full duplex: Yes
Jumbo frames support: Yes
Jumbo frames: 16000
System requirements
Windows operating systems supported: Windows 11, Windows 8, Windows 10, Windows Vista, Windows 7
Other operating systems supported: DOS
Server operating systems supported: Windows Server 2008, Windows Server 2012
Linux operating systems supported: Yes
Packaging data
Package depth: 30 mm
Package weight: 243.5 g
Package width: 155 mm
Package height: 220 mm
Packaging content
Manual: Yes
Mounting brackets included: Yes
Resource CD: Yes
Ports & interfaces
Host interface: PCI Express
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 4
Interface: Ethernet
PCI version: 2.1
Other features
Package volume: 1023 cm³
Logistics data
UK Trade Tariff code: 84718000
