Design DIN rail mounting: Yes Vandal-proof: No Rack mounting: No Product colour: Black, Blue International Protection (IP) code: IP40 Suitable for outdoor use: No Housing material: Aluminium LED indicators: Yes Stackable: No
Power DC input voltage: 12 - 52 V Power source: DC Power consumption (typical): 3 W
Operational conditions Operating temperature (T-T): -40 - 80 °C Storage relative humidity (H-H): 5 - 95% Operating relative humidity (H-H): 5 - 95% Storage temperature (T-T): -40 - 80 °C
Management features Switch type: Unmanaged
Weight & dimensions Width: 128 mm Weight: 450 g Height: 34 mm Depth: 86 mm
Network Half duplex: Yes Networking standards: IEEE 802.3u, IEEE 802.3 Auto MDI/MDI-X: Yes 10G support: No Ethernet LAN data rates: 10,100 Mbit/s Full duplex: Yes Flow control support: Yes Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 100BASE-FX VLAN support: No
Packaging data Package weight: 541.667 g Package volume: 1202.85 cm³ Package width: 135 mm Package depth: 54 mm Package height: 165 mm
