Design
Stackable: No
Vandal-proof: No
DIN rail mounting: Yes
International Protection (IP) code: IP40
LED indicators: Yes
Product colour: Black, Blue
Housing material: Aluminium
Suitable for outdoor use: No
Rack mounting: No
Power
DC input voltage: 48 - 57 V
Power source: DC
Power consumption (typical): 3 W
Operational conditions
Operating temperature (T-T): -40 - 80 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 80 °C
Storage relative humidity (H-H): 5 - 95%
Management features
Switch type: Unmanaged
Weight & dimensions
Weight: 450 g
Height: 34 mm
Depth: 86 mm
Width: 128 mm
Network
Half duplex: Yes
Full duplex: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Copper ethernet cabling technology: 1000BASE-TX, 100BASE-TX, 10BASE-T, 100BASE-FX, 10BASE-TX
Flow control support: Yes
Networking standards: IEEE 802.3, IEEE 802.3x, IEEE 802.3u
VLAN support: No
Auto MDI/MDI-X: Yes
10G support: No
Packaging data
Package weight: 558.333 g
Package height: 165 mm
Package depth: 54 mm
Package width: 135 mm
Package volume: 1202.85 cm³
Packaging content
Manual: Yes
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 4
Uplink ports quantity: 1
Basic switching RJ-45 Ethernet ports quantity: 4
SFP module slots quantity: 1
Power connector: Terminal block (6-pin)
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Other features
Bandwidth: 14 Gbit/s
Ethernet interface type: Gigabit Ethernet
Logistics data
UK Trade Tariff code: 85176200
Country of origin: China
Data transmission
Forwarding rate: 10.5 Mpps
Switching capacity: 1 Gbit/s
MAC address table: 2000 entries
Packet buffer memory: 1.2 MB
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 30 W
Power over Ethernet (PoE): No
