Technical details Package volume: 2332.75 cm³ Country of origin: China
Features Product colour: Black HDCP: Yes Cable types supported: Cat7, Cat6, Cat5e, Cat8 Supported video modes: 1080p, 2160p, 2160i, 1080i Maximum resolution: 3840 x 2160 pixels Wall mountable: Yes Type: AV transmitter & receiver HDCP version: 1.4/2.2 Maximum refresh rate: 30 Hz Bandwidth: 10.2 Gbit/s Electrostatic Discharge (ESD) protection: Yes Bidirectional: Yes Maximum transfer distance: 70 m Material: Metal LED indicators: Yes
Power Power consumption (transmitter) (max): 20 W Operating voltage (transmitter): 24 V Power over Ethernet (PoE): No Operating voltage (receiver): 24 V External power adapter: Yes Power consumption (receiver) (max): 20 W
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Transmitter dimensions (WxDxH): 115 x 65 x 17 mm Receiver dimensions (WxDxH): 115 x 65 x 17 mm Receiver weight: 200 g Transmitter weight: 200 g
Packaging data Package height: 70 mm Package weight: 825 g Package depth: 155 mm Package width: 215 mm Quantity per pack: 2 pc(s)
Packaging content Mounting brackets included: Yes Cables included: IR Manual: Yes AC adapter included: Yes
