Features HDCP: Yes Maximum resolution: 3840 x 2160 pixels High Dynamic Range (HDR) technology: High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG), High Dynamic Range 10+ (HDR10 Plus) Bidirectional: Yes High Dynamic Range (HDR) supported: Yes Cable types supported: Cat6, Cat7, Cat8 Maximum transfer distance: 100 m Electrostatic Discharge (ESD) protection: Yes Type: Transmitter & receiver Bandwidth: 18 Gbit/s Maximum refresh rate: 60 Hz HDCP version: 2.2 Material: Metal HDCP & EDID bypass: Yes Product colour: Black Extended display identification data (EDID): Yes
Power Operating voltage (transmitter): 24 V Power source type: DC External power adapter: Yes Operating voltage (receiver): 24 V Power consumption (transmitter) (max): 10 W Power consumption (receiver) (max): 10 W Power over Ethernet (PoE): No
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Receiver dimensions (WxDxH): 140 x 65 x 18 mm Receiver weight: 246 g Transmitter weight: 246 g Transmitter dimensions (WxDxH): 140 x 65 x 18 mm
Packaging data Package height: 75 mm Package width: 245 mm Package weight: 1.09 kg Package depth: 185 mm
Packaging content Manual: Yes Cables included: USB, IR AC adapter included: Yes
Ports & interfaces RJ-45 input ports: 1 HDMI version: 2.0b Connectivity technology: Wired DC-in jack: Yes HDMI in: 1 USB ports quantity: 6 Number of HDMI outputs: 1 Remote (IR) input: 2 USB connector type: USB Type-B, USB Type-A USB version: 1.1 RJ-45 output ports: 1 Remote (IR) output: 2
