Features Maximum resolution: 3840 x 2160 pixels HDCP: Yes Cable types supported: Cat8, Cat6a, Cat6, Cat7 Electrostatic Discharge (ESD) protection: Yes Product colour: Black HDCP version: 1.4 Type: AV transmitter & receiver Bandwidth: 10.2 Gbit/s Maximum transfer distance: 70 m Maximum refresh rate: 30 Hz Wall mountable: Yes Material: Metal Extended display identification data (EDID): Yes
Power Power over Ethernet (PoE): Yes Power consumption (transmitter) (max): 1.86 W, 1000 mA Operating voltage (transmitter): 12 V Operating voltage (receiver): 12 V Power consumption (receiver) (max): 0.87 W, 1000 mA
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Receiver dimensions (WxDxH): 69 x 79 x 16.5 mm Transmitter dimensions (WxDxH): 69 x 79 x 16.5 mm Transmitter weight: 130 g Receiver weight: 130 g
Packaging data Package width: 200 mm Package weight: 550 g Package height: 75 mm Quantity per pack: 1 pc(s)
Packaging content Manual: Yes Cables included: IR AC adapter included: Yes
Logistics data Master (outer) case length: 400 mm Master (outer) case height: 365 mm Master (outer) case volume: 61320 cm³ Products per master (outer) case: 30 pc(s) Master (outer) case gross weight: 16.5 kg Master (outer) case width: 420 mm UK Trade Tariff code: 85176200
Safety warning Warnings: Do not expose to extreme temperatures or moisture., Do not connect devices with higher power consumption than recommended., Keep away from children.
