Technical details
Country of origin: China
Package volume: 2372.08 cm³
Features
Supported video modes: 720p, 480p, 1080p, 2160p, 480i, 1080i, 576p, 576i
Cable types supported: Cat5, Cat5e, Cat6
Maximum transfer distance: 120 m
HDCP: Yes
Type: AV transmitter & receiver
Bandwidth: 10.2 Gbit/s
Material: Metal
Maximum resolution: 3840 x 2160 pixels
3D: Yes
Colour depth: 24 bit
Product colour: Black
Power
Operating voltage (receiver): 5 V
Output current: 2 A
Power consumption (typical): 4 W
Power over Ethernet (PoE): No
Operating voltage (transmitter): 5 V
Operational conditions
Operating temperature (T-T): 0 - 60 °C
Weight & dimensions
Height: 23.7 mm
Weight: 167 g
Depth: 94 mm
Width: 107.3 mm
Packaging data
Package height: 80 mm
Package weight: 845 g
Package width: 199 mm
Package depth: 149 mm
Packaging content
Manual: Yes
IR receiver included: Yes
IR blaster included: Yes
AC adapter included: Yes
Ports & interfaces
HDMI in: 1
Number of HDMI outputs: 1
HDMI version: 1.4
Remote (IR) output: 1
DC-in jack: Yes
Connectivity technology: Wired
RJ-45 input ports: 1
RJ-45 output ports: 1
Remote (IR) input: 1
Logistics data
UK Trade Tariff code: 85176200
