Design
Product colour: Black
Rack mounting: No
Stackable: No
LED indicators: PoE, Link, Activity, Power
Power
Power source: AC
Surge protection: Yes
Surge protection voltage: 2 kV
Power supply included: Yes
AC input frequency: 50 - 60 Hz
Power consumption (typical): 65 W
AC input voltage: 100 - 240 V
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Management features
Switch type: Managed
Weight & dimensions
Height: 32 mm
Depth: 93 mm
Width: 168 mm
Network
Ethernet LAN data rates: 10,100 Mbit/s
Full duplex: Yes
Networking standards: IEEE 802.3at, IEEE 802.3x, IEEE 802.3, IEEE 802.3af
Copper ethernet cabling technology: 10BASE-TX, 1000BASE-T
Cable types supported: Cat4, Cat5, Cat5e, Cat3
10G support: No
Half duplex: Yes
Flow control support: Yes
Performance
Mean time between failures (MTBF): 50000 h
Packaging data
Package depth: 195 mm
Package weight: 881.176 g
Package volume: 2051.59 cm³
Package width: 167 mm
Package height: 63 mm
Packaging content
Cables included: AC
Quick start guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 10
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Power connector: AC-in jack
Fast Ethernet (copper) ports quantity: 10
Other features
Bandwidth: 20 Gbit/s
Logistics data
Country of origin: China
UK Trade Tariff code: 85176200
Data transmission
Jumbo frames support: Yes
Store-and-forward: Yes
Packet buffer memory: 2 MB
Jumbo frames: 9216
MAC address table: 2000 entries
Forwarding rate: 14.88 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 60 W
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 8
