Design Vandal-proof: No Housing material: Metal Product colour: Black Wall mountable: Yes Suitable for outdoor use: No DIN rail mounting: Yes
Power Power protection features: Short circuit, Over voltage Power consumption (typical): 5 W Redundant power supply (RPS) support: Yes DC input voltage: 12 - 56 V
Operational conditions Operating temperature (T-T): -40 - 85 °C
Management features Switch type: Unmanaged
Weight & dimensions Height: 142 mm Width: 36.2 mm Weight: 520 g Depth: 105 mm
Network Auto MDI/MDI-X: Yes VLAN support: No Networking standards: IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-TX Full duplex: Yes 10G support: No Flow control support: Yes
Performance Plug and Play: Yes Mean time between failures (MTBF): 500000 h
Packaging data Package weight: 787.5 g Package width: 65 mm Package height: 215 mm Package depth: 165 mm Terminal block included: Yes Package volume: 2305.88 cm³
Other features Ethernet interface type: Gigabit Ethernet
Logistics data Products per master (outer) case: 16 pc(s) Country of origin: Taiwan UK Trade Tariff code: 85176200 Harmonized System (HS) code: 85176990 Master (outer) case gross weight: 12.6 kg Master (outer) case volume: 47040 cm³ Master (outer) case width: 240 mm Master (outer) case height: 560 mm Master (outer) case length: 350 mm
Data transmission Switching capacity: 16 Gbit/s Store-and-forward: Yes MAC address table: 8000 entries
Power over Ethernet (PoE) Power over Ethernet (PoE): No
