Features Cable shape: Round Bend radius (min): 8 mm Product colour: Yellow Cable length: 500 m Conductor type: Solid Connector 1 gender: No Frequency: 1500 MHz Jacket material: Low smoke zero halogen (LSZH) Conductor material: Copper AWG wire size: 22/1 Cable class: D Cabling technology: 10GBase-T Connector 1: No Data transfer rate: 10000 Mbit/s Power over Ethernet (PoE): Yes Cable shielding: S/FTP (S-STP) Power over Ethernet (PoE) type supported: PoE+, PoE++ (4PPoE) Connector 2: No Networking standards: IEEE 802.3, IEEE 802.5 Cable standard: Cat7a Connector 2 gender: No Cable fire class: Cca
Operational conditions Operating temperature (T-T): -20 - 60 °C Storage temperature (T-T): -20 - 60 °C
Weight & dimensions Outer diameter: 7.8 mm
Packaging data Package weight: 71 kg Package volume: 140.45 cm³ Package width: 530 mm Package depth: 500 mm Package height: 530 mm
