Design
Component for: Server
Internal: Yes
Chipset: Intel® 82575EB
Network
LAN controller: Intel® 82575EB
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Networking standards: IEEE 802.3ab, IEEE 802.1Q, IEEE 802.3x
Maximum data transfer rate: 1000 Mbit/s
Ethernet LAN: Yes
Full duplex: Yes
System requirements
Server operating systems supported: Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019
Windows operating systems supported: Windows 7, Windows 8, Windows 10, Windows 8.1
Linux operating systems supported: Yes
Other operating systems supported: FreeBSD, VMware vSphere ESXi
Packaging content
Quick installation guide: Yes
Mounting brackets included: Yes
Resource CD: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
Interface: Ethernet
Connectivity technology: Wired
Host interface: PCIe
Logistics data
Harmonized System (HS) code: 85176990
Safety warning
Warnings: The product contains electronic components and should not be disposed of in the regular rubbish bin., Please observe local regulations regarding the disposal of electronic waste., Avoid contact with liquids. If spilled, the product may be damaged.
