Features
Product colour: Black
Internal: No
LED indicators: Power, Link, Status, Activity
Power
Input voltage: 5 V
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 30 W
Output voltage: 48 - 52 V
External power adapter: Yes
Operational conditions
Storage temperature (T-T): -40 - 85 °C
Operating temperature (T-T): -20 - 65 °C
Weight & dimensions
Depth: 95 mm
Width: 71 mm
Height: 26 mm
Network
Maximum data transfer rate: 1000 Mbit/s
Auto MDI/MDI-X: Yes
Duplex system: Half, Full
Copper ethernet cabling technology: 100BASE-TX, 1000BASE-TX
Ethernet LAN data rates: 10, 1000, 100 Mbit/s
Converter input interface: 100Base-TX, 1000Base-TX
Fiber ethernet cabling technology: 1000BASE‑SX
Networking standards: IEEE 802.3at, IEEE 802.3u, IEEE 802.3, IEEE 802.3z, IEEE 802.3af
Data transfer rate: 1000 Mbit/s
Ethernet interface type: Gigabit Ethernet
Converter output interface: 1000Base-SX
Performance
Wavelength: 850 nm
Maximum transfer distance: 500 m
Mean time between failures (MTBF): 500000 h
Fiber mode structure: Multi-mode
Packaging data
Package depth: 240 mm
Package width: 130 mm
Package volume: 1872 cm³
Package weight: 800 g
Package height: 60 mm
Packaging content
Quick installation guide: Yes
AC adapter included: Yes
Ports & interfaces
Fiber ports quantity: 1
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Fiber optic connector: SC
Logistics data
UK Trade Tariff code: 85176200
Master (outer) case gross weight: 8 kg
Master (outer) case length: 570 mm
Master (outer) case volume: 65436 cm³
Harmonized System (HS) code: 85176990
Products per master (outer) case: 10 pc(s)
Country of origin: China
Master (outer) case width: 410 mm
Master (outer) case height: 280 mm
