Features
LED indicators: Status, Power, Link, Activity
Product colour: Black
Internal: No
Power
Output voltage: 48 - 52 V
Total Power over Ethernet (PoE) budget: 30 W
Power over Ethernet (PoE): Yes
Operational conditions
Operating temperature (T-T): -20 - 65 °C
Storage temperature (T-T): -40 - 85 °C
Weight & dimensions
Height: 26 mm
Width: 71 mm
Depth: 95 mm
Network
Maximum data transfer rate: 1000 Mbit/s
Ethernet LAN data rates: 10, 1000, 100 Mbit/s
Auto MDI/MDI-X: Yes
Networking standards: IEEE 802.3z, IEEE 802.3af, IEEE 802.3u, IEEE 802.3at, IEEE 802.3
Ethernet interface type: Gigabit Ethernet
Converter input interface: 1000Base-TX, 100Base-TX
Duplex system: Full, Half
Copper ethernet cabling technology: 1000BASE-TX, 100BASE-TX
Fiber ethernet cabling technology: 1000BASE‑LX
Converter output interface: 1000Base-LX
Data transfer rate: 1000 Mbit/s
Performance
Fiber mode structure: Single-mode
Maximum transfer distance: 20000 m
Wavelength: 1310 nm
Mean time between failures (MTBF): 500000 h
Packaging data
Package height: 60 mm
Package width: 130 mm
Package weight: 800 g
Package depth: 240 mm
Package volume: 1872 cm³
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Connectivity technology: Wired
Power over Ethernet (PoE) ports quantity: 1
Fiber optic connector: SC
Fiber ports quantity: 1
Logistics data
Country of origin: China
Master (outer) case height: 280 mm
Harmonized System (HS) code: 85176990
Products per master (outer) case: 10 pc(s)
Master (outer) case length: 570 mm
Master (outer) case gross weight: 8 kg
Master (outer) case width: 410 mm
Master (outer) case volume: 65436 cm³
UK Trade Tariff code: 85176200
