Features
Product colour: Black
Internal: No
LED indicators: Activity, Link, Power
Power
Total Power over Ethernet (PoE) budget: 30 W
Power over Ethernet (PoE): Yes
Output voltage: 48 - 52 V
Input voltage: 5 V
External power adapter: Yes
Operational conditions
Operating temperature (T-T): -20 - 65 °C
Storage temperature (T-T): -40 - 85 °C
Weight & dimensions
Width: 71 mm
Depth: 95 mm
Height: 26 mm
Network
Converter input interface: 1000Base-T, 100Base-T, 10Base-T
Networking standards: IEEE 802.3at, IEEE 802.3, IEEE 802.3z, IEEE 802.3u, IEEE 802.3af
Copper ethernet cabling technology: 1000BASE-T, 10BASE-T, 100BASE-T
Ethernet LAN data rates: 10, 1000, 100 Mbit/s
Maximum data transfer rate: 1000 Mbit/s
Data transfer rate: 1000 Mbit/s
Auto MDI/MDI-X: Yes
Ethernet interface type: Gigabit Ethernet
Performance
Mean time between failures (MTBF): 500000 h
Maximum transfer distance: 80000 m
Packaging data
Package weight: 800 g
Package width: 130 mm
Package volume: 1872 cm³
Package depth: 240 mm
Package height: 60 mm
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Connectivity technology: Wired
DC-in jack: Yes
Fiber ports quantity: 1
Power over Ethernet (PoE) ports quantity: 1
Fiber optic connector: SFP
Logistics data
Products per master (outer) case: 110 pc(s)
Country of origin: China
Harmonized System (HS) code: 85176990
Master (outer) case width: 410 mm
Master (outer) case gross weight: 8 kg
UK Trade Tariff code: 85176200
Master (outer) case volume: 65436 cm³
Master (outer) case length: 570 mm
Master (outer) case height: 280 mm
