Features LED indicators: Yes HDCP: Yes Electrostatic Discharge (ESD) protection: Yes Bandwidth: 18 Gbit/s Material: Metal Fiber mode structure: Single-mode, Multi-mode Maximum resolution: 3840 x 2160 pixels Supported video modes: 2160p Wall mountable: Yes Cable types supported: Fiber Maximum transfer distance: 40000 m HDCP version: 1.4/2.2 Type: Transmitter & receiver Product colour: Black Maximum refresh rate: 60 Hz RS-232 pass-through: Yes
Power Output current: 2 A Power consumption (receiver) (max): 7.5 W Operating voltage (receiver): 5 V Power consumption (transmitter) (max): 7.5 W Power source type: DC External power adapter: Yes Operating voltage (transmitter): 5 V
Operational conditions Operating temperature (T-T): -10 - 50 °C
Weight & dimensions Receiver dimensions (WxDxH): 103 x 106 x 26 mm Transmitter dimensions (WxDxH): 103 x 106 x 26 mm Receiver weight: 286 g Transmitter weight: 290 g
Packaging data Package weight: 1.14 kg Package height: 80 mm Package width: 176 mm Package depth: 240 mm
Packaging content Cables included: IR Mounting kit: Yes Quick start guide: Yes Mounting brackets included: Yes AC adapter included: Yes
