Design DIN rail mounting: Yes Stackable: No Suitable for outdoor use: No Product colour: Blue, Black Housing material: Metal Rack mounting: No International Protection (IP) code: IP40 Vandal-proof: No
Power DC input voltage: 48 - 57 V Surge protection voltage: 4 kV Redundant power supply (RPS) support: Yes Surge protection: Yes Power supply included: Yes Power consumption (typical): 8 W Power source: DC
Operational conditions Storage relative humidity (H-H): 5 - 95% Storage temperature (T-T): -40 - 80 °C Operating relative humidity (H-H): 5 - 95% Operating temperature (T-T): -40 - 80 °C
Management features Switch type: Unmanaged
Weight & dimensions Width: 143.7 mm Depth: 104 mm Weight: 700 g Height: 47.7 mm
Network Flow control support: Yes 10G support: No Networking standards: IEEE 802.3af VLAN support: No Full duplex: Yes Half duplex: Yes
Performance Mean time between failures (MTBF): 300000 h Plug and Play: Yes
Packaging data Package depth: 66 mm Package volume: 2221.16 cm³ Package width: 158 mm Package height: 213 mm Package weight: 700 g
