Design
Vandal-proof: No
International Protection (IP) code: IP40
Housing material: Metal
Rack mounting: No
LED indicators: Yes
DIN rail mounting: Yes
Suitable for outdoor use: No
Stackable: No
Product colour: Black, Blue
Power
Power consumption (typical): 18 W
Surge protection: Yes
Redundant power supply (RPS) support: Yes
Power supply included: Yes
Power source: DC/PoE
Surge protection voltage: 4 kV
DC input voltage: 12 - 48 V
Security
Loop protection: Yes
Access Control List (ACL): Yes
DHCP features: DHCP server, DHCP snooping, DHCP relay
IGMP snooping: Yes
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 80 °C
Operating temperature (T-T): -40 - 80 °C
Management features
Switch layer: L2/L3
Quality of Service (QoS) support: Yes
ARP inspection: Yes
Switch type: Managed
Weight & dimensions
Width: 175.6 mm
Depth: 135 mm
Height: 45.5 mm
Weight: 800 g
Network
VLAN support: No
Half duplex: Yes
10G support: Yes
Full duplex: Yes
Ethernet Ring Protection Switching (ERPS): Yes
Broadcast storm control: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Link aggregation: Yes
Flow control support: Yes
Port mirroring: Yes
Networking standards: IEEE 802.3af
Performance
Mean time between failures (MTBF): 300000 h
Firmware upgradeable: Yes
Packaging data
Package height: 208 mm
Package volume: 2804.88 cm³
Package depth: 72.5 mm
Package weight: 575 g
Package width: 186 mm
Packaging content
Quick start guide: Yes
Protocols
Routing protocols: VRRP, OSPFv3, RIPng, OSPF
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Fiber optic connector: SFP+
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Number of management ports: 1 pc(s)
Gigabit Ethernet (copper) ports quantity: 8
Installed SFP+ modules quantity: 4
Logistics data
UK Trade Tariff code: 85176200
Country of origin: China
Data transmission
MAC address table: 32000 entries
Jumbo frames support: Yes
Switching capacity: 1 Gbit/s
Jumbo frames: 10240
Store-and-forward: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 30 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
