Design
LED indicators: Yes
Product colour: Black, Blue
Rack mounting: No
Housing material: Metal
Vandal-proof: No
Stackable: No
DIN rail mounting: Yes
Suitable for outdoor use: No
International Protection (IP) code: IP40
Power
DC input voltage: 12 - 48 V
Surge protection voltage: 4 kV
Redundant power supply (RPS) support: Yes
Surge protection: Yes
Power consumption (typical): 18 W
Power supply included: Yes
Power source: DC
Security
DHCP features: DHCP relay, DHCP snooping, DHCP server
IGMP snooping: Yes
Access Control List (ACL): Yes
Loop protection: Yes
Operational conditions
Operating temperature (T-T): -40 - 80 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 80 °C
Management features
Quality of Service (QoS) support: Yes
Switch type: Managed
Switch layer: L2/L3
ARP inspection: Yes
Weight & dimensions
Weight: 800 g
Width: 175.6 mm
Depth: 135 mm
Height: 45.5 mm
Network
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.1x
Ethernet LAN data rates: 10,100,1000 Mbit/s
Full duplex: Yes
VLAN support: No
Link aggregation: Yes
Ethernet Ring Protection Switching (ERPS): Yes
Broadcast storm control: Yes
Port mirroring: Yes
10G support: Yes
Flow control support: Yes
Half duplex: Yes
Performance
Firmware upgradeable: Yes
Mean time between failures (MTBF): 300000 h
Packaging data
Package weight: 515 g
Package width: 186 mm
Package height: 208 mm
Package volume: 2804.88 cm³
Package depth: 72.5 mm
Packaging content
Quick start guide: Yes
Protocols
Routing protocols: VRRP, OSPFv3, RIPng, OSPF
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
Installed SFP+ modules quantity: 4
Number of management ports: 1 pc(s)
Gigabit Ethernet (copper) ports quantity: 8
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Fiber optic connector: SFP+
Other features
Ethernet interface type: Gigabit Ethernet
Logistics data
Country of origin: China
UK Trade Tariff code: 85176200
Data transmission
Switching capacity: 1 Gbit/s
Jumbo frames: 10240
MAC address table: 32000 entries
Jumbo frames support: Yes
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
