Features
Digital Diagnostics Monitoring (DDM): No
Housing material: Metal
DIN rail mounting: Yes
International Protection (IP) code: IP40
Internal: No
LED indicators: Status, Activity
Product colour: Blue, Black
Power
Power consumption (typical): 3 W
Power over Ethernet (PoE): No
Input voltage: 12 - 48 V
Operational conditions
Operating temperature (T-T): -40 - 80 °C
Weight & dimensions
Width: 118 mm
Depth: 92.4 mm
Height: 40 mm
Network
Data transfer rate: 1000 Mbit/s
Copper ethernet cabling technology: 1000BASE-T, 10BASE-T, 100BASE-T
Converter input interface: 1000Base-T, 10Base-T, 100Base-T
Ethernet interface type: Gigabit Ethernet
Converter output interface: 1000Base-SX
Fiber ethernet cabling technology: 1000BASE‑SX
Auto MDI/MDI-X: Yes
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
Maximum data transfer rate: 1000 Mbit/s
Performance
Maximum transfer distance: 20000 m
Fiber mode structure: Single-mode
Fiber cable diameters supported (core/cladding): 50/125 µm, 62.5/125, 100/140 µm
Wavelength: 1310 nm
Packaging data
Package volume: 1202.85 cm³
Package height: 165 mm
Package depth: 54 mm
Package width: 135 mm
Package weight: 558.333 g
Packaging content
Quick installation guide: Yes
Ports & interfaces
Fiber ports quantity: 2
Fiber optic connector: SC
Ethernet LAN (RJ-45) ports: 1
Connectivity technology: Wired
Logistics data
UK Trade Tariff code: 85176200
Country of origin: China
