Design
LED indicators: Yes
Housing material: Metal
Rack mounting: No
Product colour: Black
Push button: Yes
Display switch button: Yes
Power
Power consumption (typical): 11.75 W
Output current: 3 A
AC input frequency: 50 - 60 Hz
Input current: 0.6 A
Output voltage: 5 V
Input voltage: 100 - 240, 5 V
External power adapter: Yes
Operational conditions
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 10 - 85%
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -10 - 80 °C
Weight & dimensions
Height: 26 mm
Weight: 505.4 g
Depth: 243 mm
Width: 75 mm
System requirements
Mac operating systems supported: Yes
Windows operating systems supported: Windows 8, Windows XP, Windows 11, Windows Vista, Windows 7, Windows 10
Server operating systems supported: Windows 2000 Server
Linux operating systems supported: Yes
Performance
Maximum resolution: 4096 x 2160 pixels
Plug and Play: Yes
HDCP: Yes
HD type: 4K Ultra HD
Video bandwidth: 60 Hz
Packaging data
Package weight: 1.33 kg
Package volume: 2691 cm³
Package width: 230 mm
Package depth: 180 mm
Display
Built-in display: No
Ports & interfaces
DC-in jack: Yes
Video port type: HDMI/DisplayPort
DisplayPort version: 1.2
HDMI ports quantity: 1
HDMI version: 2.0
DisplayPorts quantity: 5
Console ports: USB B, 3.5mm headphone, 3.5mm mic, DisplayPort
Keyboard port type: USB
Mouse port type: USB
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 2
USB 2.0 Type-A hub ports quantity: 2
Other features
Ports quantity: 8
Logistics data
Harmonized System (HS) code: 85176200
UK Trade Tariff code: 84718000
