Features
Surge protection features: Network, Digital Subscriber Line (DSL), Modem
UPS topology: Line-Interactive
Output voltage regulation: 10%
Output power capacity: 0.6 kVA
Number of input phases: 1
Input operation voltage (min): 162 V
Input operation voltage (max): 290 V
Power protection features: Overload, Battery discharge, Overcharge
Automatic Voltage Regulation (AVR): Yes
Power factor: 0.6
Audible alarm(s): Yes
Transfer time (Line Mode to Battery Mode): 2 ms
Number of output phases: 1
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Auto-restart: Yes
Noise level: 40 dB
Waveform: Pseudo sine
Surge protection: Yes
Output frequency: 50 Hz
Input frequency: 50 Hz
Output power: 600 W
Design
Form factor: Tower
LED indicators: Yes
Display type: LCD
Product colour: Black
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Depth: 338 mm
Height: 162 mm
Width: 150 mm
Weight: 7.8 kg
Packaging data
Package width: 235 mm
Package height: 192 mm
Package volume: 18273.6 cm³
Ports & interfaces
AC outlets quantity: 4 AC outlet(s)
AC outlet types: Type E / F
USB 2.0 ports quantity: 1
Power plug: Type F
USB port type: USB Type-B
Serial interface: Yes
RS-232 ports: 1
Ethernet LAN (RJ-45) ports: 2
USB port: Yes
Serial ports quantity: 1
Serial interface type: RS-232
Battery
Battery voltage: 12 V
Cold start: Yes
Number of batteries supported: 2
Battery capacity: 7 Ah
Battery recharge time (90%): 6 h
Output connections: 4 x CEE 7/7
Other features
Nominal input voltage: 230 V
Nominal output voltage: 230 V
Logistics data
Harmonized System (HS) code: 85078000
UK Trade Tariff code: 85044085
Safety warning
Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating., Keep away from sources of fire and water.
