Features
Input operation voltage (max): 290 V
Input operation voltage (min): 162 V
Number of input phases: 1
Noise level: 40 dB
UPS topology: Line-Interactive
Surge protection: Yes
Output frequency: 50 Hz
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Input frequency: 50 Hz
Output voltage regulation: 10%
Waveform: Pseudo sine
Audible alarm(s): Yes
Output power capacity: 0.8 kVA
Surge protection features: Modem
Power protection features: Battery discharge, Overload, Overcharge
Auto-restart: Yes
Transfer time (Line Mode to Battery Mode): 2 ms
Automatic Voltage Regulation (AVR): Yes
Number of output phases: 1
Output power: 480 W
Design
LED indicators: Yes
Form factor: Tower
Product colour: Black
Display type: LCD
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Depth: 298 mm
Width: 101 mm
Height: 142 mm
Weight: 4.35 kg
Packaging data
Package volume: 10586.1 cm³
Package width: 142 mm
Package height: 213 mm
Ports & interfaces
Power plug: Type F
USB port: No
AC outlets quantity: 2 AC outlet(s)
Battery
Battery recharge time (90%): 6 h
Number of batteries supported: 1
Battery capacity: 7 Ah
Battery voltage: 12 V
Cold start: Yes
Other features
Nominal input voltage: 230 V
Nominal output voltage: 230 V
Logistics data
UK Trade Tariff code: 85044085
Harmonized System (HS) code: 85078000
Safety warning
Warnings: Use the appliance in well-ventilated areas to avoid overheating., Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water.
