Features
Surge protection features: Network, Digital Subscriber Line (DSL), Modem
Audible alarm(s): Yes
Output voltage regulation: 10%
UPS topology: Line-Interactive
Output power capacity: 1.5 kVA
Waveform: Pseudo sine
Auto-restart: Yes
Number of output phases: 1
Number of input phases: 1
Input operation voltage (min): 162 V
Output power: 1200 W
Input operation voltage (max): 290 V
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Input frequency: 50/60 Hz
Noise level: 40 dB
Surge protection: Yes
Transfer time (Line Mode to Battery Mode): 2 ms
Output frequency: 50 Hz
Automatic Voltage Regulation (AVR): Yes
Power factor: 0.6
Design
Form factor: Tower
Display type: LCD
Product colour: Black
LED indicators: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Width: 158 mm
Height: 198 mm
Depth: 380 mm
Weight: 10.5 kg
Packaging data
Package width: 212 mm
Package height: 280 mm
Package volume: 26237.1 cm³
Ports & interfaces
RS-232 ports: 1
AC outlets quantity: 4 AC outlet(s)
AC outlet types: Type E / F
Serial interface type: RS-232
Ethernet LAN (RJ-45) ports: 2
Serial interface: Yes
USB port type: USB Type-B
USB 2.0 ports quantity: 1
USB port: Yes
Serial ports quantity: 1
Power plug: Type F
Battery
Cold start: Yes
Battery voltage: 12 V
Battery recharge time (90%): 6 h
Number of batteries supported: 2
Battery capacity: 9 Ah
Other features
Nominal input voltage: 230 V
Nominal output voltage: 230 V
Logistics data
UK Trade Tariff code: 85044085
Harmonized System (HS) code: 85078000
Safety warning
Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water., Use the appliance in well-ventilated areas to avoid overheating.
