Technical details Sustainability certificates: ENERGY STAR Sustainability compliance: Yes Compliance certificates: CE
Features UPS topology: Line-Interactive Power protection features: Overdischarge Output power capacity: 3 kVA Waveform: Pure sine Input operation voltage (max): 294 V Input operation voltage (min): 160 V Output power: 3000 W Input frequency: 47/70 Hz Noise level: 40 dB Certification: IEC/EN 62040-2, FCC B, CISPR22 B
CB (TUV) / cTUVus / EAC / UKCA / Ukr / Cm
Design Product colour: Black LED indicators: Yes Rack capacity: 3U Form factor: Rackmount/Tower Safety: IEC/EN 62040-1, UL1778, CSA22.2 Display type: LCD
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Weight: 31.1 kg Width: 438 mm Height: 129 mm Depth: 483 mm
Packaging data Management card included: No
Ports & interfaces AC outlets quantity: 10 AC outlet(s) Serial ports quantity: 1 AC outlet types: C13 coupler, C19 coupler Serial interface: Yes Power plug: C20 coupler USB port: Yes Serial interface type: RS-232
Battery Hot-swap battery: Yes Automatic battery test: Yes Output connections: 8 x IEC C13 (10A)
2 x IEC C19 (16A)
Other features Nominal output voltage: 230 V
Logistics data Harmonized System (HS) code: 85078000
