Technical details Sustainability compliance: Yes Sustainability certificates: CE
Features Output frequency: 50/60 Hz Waveform: Sine Audible alarm(s): Yes Output power capacity: 2 kVA Efficiency (ECO mode): 96.5% Input power factor: 99 Number of output phases: 1 Input frequency: 40/70 Hz Output power factor: 0.9 UPS topology: Double-conversion (Online) Power source type: AC Output operation voltage (max): 240 V Noise level: 45 dB Efficiency: 91% Output operation voltage (min): 220 V Output power: 1800 W Input operation voltage (min): 140 V Number of input phases: 1 Heat dissipation: 546 BTU/h Input operation voltage (max): 276 V Certification: IEC/EN 62040-1
IEC/EN 62040-2
CE
Design Form factor: Tower Rack capacity: 2U Product colour: Black Control type: Buttons LED indicators: Yes Display type: LCD
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 96%
Weight & dimensions Height: 86.5 mm Depth: 608 mm Weight: 29.9 kg Width: 438 mm
Packaging data Cables included: Output power cable, USB cable Quick installation guide: Yes Rack mount kit: Yes
Ports & interfaces USB port: Yes Serial ports quantity: 1 AC outlet types: C14 coupler, C13 coupler Serial interface: Yes Serial interface type: RS-232 AC outlets quantity: 6 AC outlet(s) RS-232 ports: 1 Power plug: C13 coupler
Battery Number of batteries supported: 6 Typical backup time at half load: 12 min Battery voltage: 12 V Battery capacity: 7 Ah Battery technology: Lead-Acid Typical backup time at full load: 4.5 min
