Features UPS topology: Double-conversion (Online) Waveform: Pure sine Output frequency: 50/60 Hz Output power: 2200 W Power factor: 1 Output operation voltage (min): 200 V Output power capacity: 2.2 kVA Efficiency: 93.5% Output operation voltage (max): 240 V Input operation voltage (min): 176 V Input frequency: 40/70 Hz Number of input phases: 1 Input operation voltage (max): 276 V Noise level: 40 dB
Design LED indicators: Yes Product colour: Black Rack capacity: 2U Display type: LCD Form factor: Rackmount/Tower
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Weight: 25 kg Depth: 605 mm Width: 440 mm Height: 86.5 mm Bundled software: Intelligent Power Software suite
Packaging data Management card included: Yes
Packaging content Rack mount kit: Yes
Ports & interfaces AC outlets quantity: 10 AC outlet(s) USB 2.0 ports quantity: 1 Power plug: C20 coupler AC outlet types: C19 coupler, C13 coupler RS-232 ports: 1 USB port: Yes
Battery Typical backup time at half load: 10 min Hot-swap battery: Yes Battery technology: Sealed Lead Acid (VRLA) Automatic battery test: Yes
Other features Nominal input voltage: 230 V Nominal output voltage: 230 V
Logistics data Harmonized System (HS) code: 85078000
Sustainability Sustainability certificates: ENERGY STAR
