Design Fan location: Top Product colour: Black On/off switch: Yes Fan diameter: 12 cm Number of fans: 1 fan(s) Cooling type: Active
Power Max output current (-12V): 0.3 A Power protection features: OPP (overload protection), SIP (surge and shock protection), SCP (short circuit protection), OVP (overvoltage protection), UVP (undervoltage protection) Max output current (+5V): 18 A AC input frequency: 50 - 60 Hz Max output current (+12V): 41 A Total power: 550 W Max output current (+3.3V): 18 A Max output current (+5Vsb): 2.5 A Power Factor Correction (PFC) type: Active
Weight & dimensions Width: 150 mm Height: 87 mm Depth: 140 mm
Performance Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS
Packaging data DFU / User manual: Y
Ports & interfaces Length of EPS power connectors (4+4 pin) : 70 cm Peripheral (Molex) power connectors (4-pin): 2 EPS power connector (4+4 pin): Yes Number of SATA power connectors: 4 PCI Express power connectors (6+2 pin): 1 PCI Express power cable length: 46 cm SATA power cable length: 410, 700 mm Motherboard power cable length: 45 cm Motherboard power connector: 20+4 pin ATX
