Design
Fan speed: 0 - 1400 RPM
Fan location: Top
Product colour: Black
Cooling type: Active
Number of fans: 1 fan(s)
Fan diameter: 12 cm
On/off switch: Yes
Power
Max output current (+3.3V): 20 A
AC input voltage: 230 V
Total power: 500 W
Power protection features: Over power, Short circuit, Over voltage, Under voltage, Over current
Max output current (+12V): 70 A
Max output current (+5Vsb): 3 A
Max output current (-12V): 0.3 A
Operational conditions
Operating temperature (T-T): 0 - 105 °C
Weight & dimensions
Depth: 140 mm
Weight: 2.06 kg
Width: 150 mm
Height: 87 mm
Performance
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Bronze
Purpose: PC
Mean time between failures (MTBF): 80000 h
Supported motherboard form factors: ATX, micro BTX, Mini-ATX
Bearing technology: FDB
Packaging data
Package type: Box
Packaging content
Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Ports & interfaces
EPS power connector (4+4 pin): Yes
Peripheral (Molex) power cable length: 820 mm
Cabling type: Non-Modular
SATA power cable length: 820 mm
Motherboard power connector: 24-pin ATX
Peripheral (Molex) power connectors (4-pin): 1
PCI Express power connectors (6+2 pin): 1
Number of SATA power connectors: 5
PCI Express power cable length: 56 cm
Motherboard power cable length: 57 cm
