Technical details
Doesn't contain: Cadmium, Mercury, Lead
Design
Fan diameter: 12 cm
Number of fans: 1 fan(s)
On/off switch: Yes
Illumination: No
Product colour: Black
Cooling type: Active
Power
Max output current (+5Vsb): 3 A
Max output current (+5V): 20 A
Input current: 5 A
AC input frequency: 50 Hz
Max output current (+12V): 54 A
Combined power (+5V): 100 W
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 100 W
AC input voltage: 200 - 240 V
Combined power (+5Vsb): 15 W
Combined power (+12V): 648 W
Max output current (+3.3V): 20 A
Total power: 650 W
Power protection features: Short circuit, Over voltage, Under voltage, Over current, Over power, Surge & inrush protection (SIP), Overheating
Weight & dimensions
Width: 150 mm
Height: 87 mm
Weight: 1.57 kg
Depth: 140 mm
Performance
ATX version: 3.1
Mean time between failures (MTBF): 80000 h
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Bronze
Bearing technology: FDB
Purpose: PC
Packaging data
Package weight: 2.09 kg
Package depth: 220 mm
Manual: Yes
Package width: 273 mm
Package height: 100 mm
Packaging content
Cables included: AC
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance: Yes
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC), CCC, UKCA
Ports & interfaces
PCI Express power connectors (16-pin): 1
EPS power connector (4+4 pin): Yes
Peripheral (Molex) power cable length: 800
Number of SATA power connectors: 5
Motherboard power connector: 24-pin ATX
ATX Power connector (24-pin): Yes
Peripheral (Molex) power connectors (4-pin): 1
PCI Express power connectors (6+2 pin): 2
SATA power cable length: 500, 800
Cabling type: Non-Modular
Motherboard power cable length: 57 cm
Logistics data
Warranty period: 5 year(s)
