Power Power protection features: Over voltage, Under voltage, Over power Input current: 5 A AC input voltage: 200 - 240 V AC input frequency: 50/60 Hz Combined power (+12V): 492 W Combined power (+3.3V): 100 W Combined power (-12V): 3.6 W Max output current (+3.3V): 15 A Max output current (+12V): 41 A Max output current (-12V): 0.3 A Max output current (+5Vsb): 2.5 A Total power: 550 W Combined power (+5V): 100 W Max output current (+5V): 15 A Combined power (+5Vsb): 12.5 W
Weight & dimensions Height: 86 mm Depth: 140 mm Width: 150 mm
Performance Purpose: PC 80 PLUS certification: 80 PLUS Mean time between failures (MTBF): 100000 h
Ports & interfaces EPS power connector (4+4 pin): Yes Motherboard power connector: 20+4 pin ATX Cabling type: Non-Modular PCI Express power connectors (6+2 pin): 2
