Power Power protection features: Short circuit, Over voltage, Under total voltage, Over power Max output current (-12V): 0.3 A Total power: 650 W Max output current (+5V): 15 A Combined power (-12V): 3.6 W AC input voltage: 220 - 240 V Combined power (+5Vsb): 12.5 W Input current: 5 A Max output current (+12V): 49 A Combined power (+3.3V): 100 W Combined power (+5V): 588 W Max output current (+3.3V): 15 A Max output current (+5Vsb): 2.5 A Combined power (+12V): 100 W AC input frequency: 50/60 Hz
Weight & dimensions Height: 86 mm Depth: 140 mm Width: 150 mm
Performance Purpose: PC Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS
Ports & interfaces EPS power connector (4+4 pin): Yes Cabling type: Non-Modular Motherboard power connector: 20+4 pin ATX PCI Express power connectors (6+2 pin): 2
