Power Total power: 750 W Combined power (+12V): 672 W Combined power (-12V): 3.6 W Max output current (+5Vsb): 2.5 A Max output current (+12V): 56 A Power protection features: Under voltage, Over power, Short circuit, Over voltage Input current: 5 A Combined power (+5Vsb): 12.5 W Max output current (+5V): 15 A AC input voltage: 200 - 240 V Combined power (+5V): 100 W Combined power (+3.3V): 100 W Max output current (+3.3V): 15 A AC input frequency: 50/60 Hz Max output current (-12V): 0.3 A
Weight & dimensions Depth: 140 mm Height: 86 mm Width: 150 mm
Performance Purpose: PC Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS
Ports & interfaces EPS power connector (4+4 pin): Yes PCI Express power connectors (6+2 pin): 4 Cabling type: Non-Modular Motherboard power connector: 20+4 pin ATX
