Design On/off switch: Yes Fan diameter: 13.5 cm Product colour: Black
Power Max output current (+5Vsb): 3 A Combined power (+12V): 1200 W Combined power (-12V): 4.8 W Input current: 8 - 15 A Combined power (+3.3V): 100 W Max output current (+12V): 100 A Combined power (+5Vsb): 15 W AC input voltage: 100 - 240 V Power protection features: Under voltage, Over current, Overheating, Over power, Overload, Short circuit Total power: 1200 W Efficiency: 92% Max output current (+5V): 10 A AC input frequency: 50/60 Hz Max output current (-12V): 0.4 A Max output current (+3.3V): 20 A Combined power (+5V): 100 W
Weight & dimensions Depth: 86 mm Height: 150 mm Width: 150 mm
Performance Purpose: PC 80 PLUS certification: 80 PLUS Gold Mean time between failures (MTBF): 100000 h Power supply unit (PSU) form factor: ATX Cybenetics certification: Platinum
Packaging data Package height: 130 mm Package width: 330 mm Package weight: 3.19 kg Package depth: 195 mm
Certificates Compliance certificates: EAC, Federal Communications Commission (FCC), CE
Ports & interfaces Number of SATA power connectors: 8 PCI Express power connectors (6+2 pin): 3 SATA power cable length: 900 mm Motherboard power cable length: 60 cm Peripheral (Molex) power cable length: 900 mm Peripheral (Molex) power connectors (4-pin): 4 PCI Express power cable length: 60 cm CPU power connector (4+4 pin): Yes Cabling type: Fully-Modular Motherboard power connector: 24-pin ATX CPU power cable length: 70 cm PCI Express power connectors (12+4 pin): 1 Number of SATA power cables: 2 ATX power connector (12+4 pin): Yes PCI Express power connectors (12+4 pin) cable length: 600 mm
Logistics data Master (outer) case length: 345 mm Master (outer) case net weight: 20.7 kg Master (outer) case height: 290 mm Master (outer) case width: 605 mm
