Design
Cooling type: Active
Product colour: Black
On/off switch: Yes
Fan diameter: 14 cm
Illumination: Yes
Fan location: Top
Power
AC input frequency: 50/60 Hz
Input current: 15 - 8 A
AC input voltage: 115 - 240 V
Power protection features: Short circuit, Over voltage, Over power, Under voltage, Over current, Overheating
Max output current (+12V1): 137.5 A
Maximum input current (@220V): 8 A
Max output current (+5Vsb): 3 A
Total power: 1650 W
Max output current (+5V): 25 A
Maximum input current (@110V): 15 A
Max output current (+3.3V): 25 A
Max output current (-12V): 0.3 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth: 170 mm
Width: 150 mm
Height: 86 mm
Performance
Supported motherboard form factors: ATX
Bearing technology: DBB
ATX version: 3.0
Purpose: PC
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Gold
Mean time between failures (MTBF): 100000 h
Noise level: 30 dB
Silent mode: Yes
Packaging data
Package weight: 4.43 kg
Package type: Box
Package height: 115 mm
Package depth: 360 mm
Package width: 210 mm
Packaging content
Cables included: AC
Ports & interfaces
CPU power cable length: 70 cm
Peripheral (Molex) power connectors (4-pin): 6
PCI Express power connectors (6+2 pin): 7
Floppy disk drive cable length: 10 cm
PCI Express connector: Yes
SATA power cable length: 600, 750, 450, 900 mm
Peripheral (Molex) power cable length: 650, 500 mm, 800 mm
Motherboard power cable length: 65 cm
Floppy disk drive connector: Yes
Cabling type: Fully-Modular
Motherboard power connector: 20+4 pin ATX
Number of SATA power connectors: 12
CPU power connector (4+4 pin): Yes
PCI Express power cable length: 80 cm
