Power AC input frequency: 50/60 Hz Combined power (+12V): 649.2 W Max output current (+3.3V): 20 A Power protection features: Under voltage, Over current, Over voltage, Over power, Static electricity Max output current (+12V1): 54.1 A Combined power (+3.3V): 100 W AC input voltage: 100 - 240 V Input current: 10-6 A Total power: 650 W Max output current (-12V): 0.4 A Max output current (+5V): 20 A Combined power (+5V): 100 W Max output current (+5Vsb): 2.5 A
Weight & dimensions Height: 86 mm Depth: 140 mm Width: 150 mm
Performance Purpose: PC Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Gold Mean time between failures (MTBF): 100000 h
Packaging data Package weight: 1.5 kg Package width: 190 mm Package depth: 310 mm Package height: 110 mm
Ports & interfaces Motherboard power connector: 20+4 pin ATX Cabling type: Non-Modular EPS power connector (4+4 pin): No
