Power AC input voltage: 100 - 240 V Input current: 10-6 A AC input frequency: 50/60 Hz Total power: 750 W Combined power (-12V): 4.8 W Max output current (+5V): 20 A Combined power (+5Vsb): 12.5 W Combined power (+12V): 748.8 W Max output current (+12V1): 62.4 A Max output current (+3.3V): 20 A Max output current (+5Vsb): 2.5 A Combined power (+3.3V): 100 W Max output current (-12V): 0.4 A
Weight & dimensions Height: 86 mm Width: 150 mm Depth: 140 mm
Performance Purpose: PC 80 PLUS certification: 80 PLUS Gold Mean time between failures (MTBF): 100000 h Power supply unit (PSU) form factor: ATX
Packaging data Package depth: 310 mm Package height: 110 mm Package width: 190 mm Package weight: 1.5 kg
Ports & interfaces PCI Express power connectors (6+2 pin): 1 Cabling type: Fully-Modular EPS power connector (4+4 pin): Yes Motherboard power connector: 20+4 pin ATX
