Power Max output current (+5V): 20 A AC input voltage: 100 - 240 V Input current: 10-6 A Combined power (+3.3V): 100 W Max output current (+5Vsb): 2.5 A Combined power (+12V): 748.8 W Power protection features: Under voltage, Over current, Short circuit, Over voltage, Over power Combined power (+5V): 100 W Total power: 750 W Max output current (+12V1): 62.4 A Max output current (+3.3V): 20 A AC input frequency: 50/60 Hz Max output current (-12V): 0.4 A
Weight & dimensions Height: 86 mm Width: 150 mm Depth: 140 mm
Performance Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold Power supply unit (PSU) form factor: ATX Purpose: PC
Packaging data Package weight: 1.6 kg Package height: 110 mm Package depth: 310 mm Package width: 190 mm
Ports & interfaces EPS power connector (4+4 pin): No Motherboard power connector: 20+4 pin ATX Cabling type: Non-Modular
