Power Max output current (+12V1): 70.8 A Total power: 850 W Max output current (+5Vsb): 2.5 A Combined power (+3.3V): 100 W Combined power (+12V): 849.6 W Combined power (+5V): 100 W Max output current (+3.3V): 20 A Max output current (+5V): 20 A Max output current (-12V): 0.4 A Power protection features: Short circuit, Over voltage, Under voltage, Over current, Over power AC input frequency: 50/60 Hz AC input voltage: 100 - 240 V Input current: 10-6 A
Weight & dimensions Height: 86 mm Width: 150 mm Depth: 140 mm
Performance Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold Purpose: PC
Packaging data Package depth: 310 mm Package weight: 1.6 kg Package height: 110 mm Package width: 190 mm
Ports & interfaces Number of SATA power connectors: 12 Motherboard power connector: 20+4 pin ATX PCI Express power connectors (6+2 pin): 1 Cabling type: Fully-Modular EPS power connector (4+4 pin): Yes
