Design
Fan connector: 4-pin
Number of fans: 1 fan(s)
Number of heat pipes: 5
Power
Thermal Design Power (TDP): 230 W
Rated voltage: 12 V
Weight & dimensions
Package height: 130 mm
Height: 163 mm
Heat pipes diameter: 6 mm
Depth: 109.5 mm
Weight: 1.39 kg
Package width: 220 mm
Width: 144.2 mm
Package depth: 175 mm
Fan dimensions (W x D x H): 140 x 140 x 25 mm
Performance
Suitable location: Processor
Supported processor sockets: LGA 1156 (Socket H), Socket FM1, Socket AM4, LGA 1366 (Socket B), LGA 1155 (Socket H2), Socket 755, Socket AM3+, Socket FM2+, LGA 1151 (Socket H4), LGA 2011-v3 (Socket R), Socket AM2+, LGA 1150 (Socket H3), LGA 2066
Maximum air pressure: 2.13 mmH2O
Rotational speed (min): 500 RPM
Airflow: 55.45 m³/h
Noise level (low speed): 13 dB
Maximum airflow: 94.21 cfm
Minimum air pressure: 0.57 mmH2O
Noise level (high speed): 22 dB
Minimum airflow (imperial): 29.78 cfm
Rotational speed (max): 1000 RPM
Type: Cooler
Fan diameter: 14 cm
Mean time between failures (MTBF): 160000 h
Pulse-width modulation (PWM) support: Yes
Packaging content
Mounting kit: Yes
Other features
Heatsink dimensions (W x D x H): 135.2 x 65 x 160 mm
Thermal grease: Yes
Logistics data
Harmonized System (HS) code: 84733080
