Design
Number of fans: 3 fan(s)
Radiator material: Aluminum
Illumination LED: Yes
Fan connector: 8-pin
Illumination colour: Multi
Product colour: Black
Number of fan blades: 5
Base plate material: Copper
Power
Fan current: 0.08 A
Thermal Design Power (TDP): 420 W
Fan voltage: 12 V
Pump current: 430 mA
Pump voltage: 12 V
Weight & dimensions
Package height: 154 mm
Package width: 518 mm
Package depth: 207 mm
Fan dimensions (W x D x H): 140 x 140 x 26.8 mm
VRM fan diameter: 6 cm
Radiator width: 46 cm
Tube length: 40 cm
Radiator height: 3.8 cm
Radiator depth: 14 cm
Performance
Supported processor sockets: LGA 2066, LGA 2011 (Socket R), LGA 1200 (Socket H5), LGA 1155 (Socket H2), LGA 1151 (Socket H4), LGA 2011-v3 (Socket R), LGA 1366 (Socket B), LGA 1150 (Socket H3), Socket AM5, LGA 1156 (Socket H), LGA 1700, Socket AM4
Maximum airflow: 78.76 cfm
Pump motor speed (min): 1200 RPM
Mean time between failures (MTBF): 50000 h
Bearing type: Ceramic bearing
Fan noise level (max): 25.47 dB
Quantity per pack: 1 pc(s)
Fan diameter: 14 cm
Maximum air pressure: 2.71 mmH2O
Rotational speed (max): 1700 RPM
Type: Liquid cooling kit
Rotational speed (min): 500 RPM
Pulse-width modulation (PWM) support: Yes
Pump motor speed (max): 3000 RPM
VRM fan speed (max): 3000 RPM
VRM fan speed (min): 500 RPM
Suitable location: Processor
Fan's mean time to failure (MTTF): 60000 h
Packaging content
Screws included: Yes
Package type: Box
Cables included: SATA
Number of clips: 3
Number of washers included: 4
Thermal pad included: Yes
CPU socket spacer(s): Yes
RGB controller included: Yes
CPU bracket(s): Yes
Other features
Tube material: Rubber
Logistics data
Master (outer) case length: 322 mm
Master (outer) case height: 450 mm
Master (outer) case width: 538 mm
Products per master (outer) case: 4 pc(s)
