Design Fan location: Top Product colour: Black On/off switch: Yes Cooling type: Active Number of fans: 1 fan(s)
Power Power protection features: Short circuit, Over voltage, Overheating, Over power, Under voltage, Over current AC input voltage: 100 - 240 V Max output current (+5Vsb): 3 A Total power: 750 W Input current: 10 A Max output current (+5V): 20 A Combined power (+12V): 849.6 W AC input frequency: 50/60 Hz Max output current (+3.3V): 20 A Combined power (+5V): 100 W Combined power (+3.3V): 100 W Max output current (+12V1): 70.8 A
Weight & dimensions Height: 86 mm Width: 122 mm Depth: 150 mm
Performance 80 PLUS certification: 80 PLUS Gold Mean time between failures (MTBF): 100000 h Power supply unit (PSU) form factor: ATX Purpose: PC ATX version: 3.1
Ports & interfaces PCI Express power connectors (6+2 pin): 3 Peripheral (Molex) power connectors (4-pin): 4 Number of SATA power connectors: 8 Peripheral (Molex) power cable length: 150, 450 mm CPU power cable length: 70 cm Cabling type: Fully-Modular ATX power connector (20+4 pin): Yes SATA power cable length: 115, 450 Motherboard power connector: 20+4 pin ATX CPU power connector (4+4 pin): Yes PCI Express power connectors (12+4 pin) cable length: 600 mm PCI Express power connectors (12+4 pin): 1
