Design On/off switch: Yes Fan location: Top Cooling type: Active Number of fans: 1 fan(s) Product colour: Black
Power AC input frequency: 50/60 Hz Combined power (+3.3V): 100 W Total power: 850 W Combined power (+12V): 849.6 W Combined power (+5V): 100 W Max output current (+12V1): 70.8 A Power protection features: Under voltage, Over current, Short circuit, Over voltage, Overheating, Over power Max output current (+3.3V): 20 A AC input voltage: 100 - 240 V Input current: 10 A Max output current (+5Vsb): 3 A Max output current (+5V): 20 A
Weight & dimensions Height: 86 mm Width: 122 mm Depth: 150 mm
Performance Purpose: PC ATX version: 3.1 Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 4 PCI Express power connectors (6+2 pin): 3 Cabling type: Fully-Modular CPU power connector (4+4 pin): Yes Peripheral (Molex) power cable length: 150, 450 mm ATX power connector (20+4 pin): Yes SATA power cable length: 450, 115 PCI Express power connectors (12+4 pin) cable length: 600 mm Motherboard power connector: 20+4 pin ATX Number of SATA power connectors: 8 PCI Express power connectors (12+4 pin): 1 CPU power cable length: 70 cm
