Design Fan location: Top On/off switch: Yes Cooling type: Active Product colour: White Number of fans: 1 fan(s)
Power Total power: 850 W Combined power (+3.3V): 100 W Max output current (+5Vsb): 3 A Max output current (+12V1): 70.8 A Combined power (+5V): 100 W Max output current (+3.3V): 20 A Max output current (+5V): 20 A Combined power (+12V): 849.6 W AC input frequency: 50/60 Hz Power protection features: Overheating, Short circuit, Over voltage, Over power, Under voltage, Over current AC input voltage: 100 - 240 V Input current: 10 A
Weight & dimensions Depth: 150 mm Width: 122 mm Height: 86 mm
Performance Power supply unit (PSU) form factor: ATX Purpose: PC ATX version: 3.1 Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold
Ports & interfaces PCI Express power connectors (6+2 pin): 3 Cabling type: Fully-Modular Peripheral (Molex) power cable length: 450 mm, 150 Motherboard power connector: 20+4 pin ATX SATA power cable length: 115, 450 ATX power connector (20+4 pin): Yes Number of SATA power connectors: 8 CPU power connector (4+4 pin): Yes CPU power cable length: 70 cm PCI Express power connectors (12+4 pin) cable length: 600 mm PCI Express power connectors (12+4 pin): 1 Peripheral (Molex) power connectors (4-pin): 4
