Features
VLAN support: Yes
Maximum data transfer rate (2.4 GHz): 1148 Mbit/s
MIMO type: Multi User MIMO
Maximum data transfer rate (5 GHz): 2400 Mbit/s
Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11ax, IEEE 802.11g, IEEE 802.11n
2.4 GHz: Yes
5 GHz: Yes
Maximum data transfer rate: 2400 Mbit/s
Ethernet LAN data rates: 10, 100 Mbit/s, 1000
MIMO: Yes
Quality of Service (QoS) support: Yes
Design
Product colour: Grey
Power
DC voltage range: 12 V
Power over Ethernet (PoE): Yes
Input current: 2 A
Security
IGMP snooping: Yes
Security algorithms: WPA2-Enterprise, WPA3
MAC address filtering: Yes
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 0 - 50 °C
Management features
Switch type: Managed
Web-based management: Yes
Weight & dimensions
Height: 33.2 mm
Width: 205.7 mm
Depth: 205.7 mm
Weight: 570 g
Packaging data
Package height: 247 mm
Package depth: 87 mm
Package weight: 870 g
Package width: 247 mm
Protocols
Management protocols: SNTP
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Antenna
Antenna direction type: Omni-directional
Antenna type: Internal
Logistics data
Harmonized System (HS) code: 85176990
Master (outer) case length: 500 mm
Master (outer) case height: 280 mm
Products per master (outer) case: 10 pc(s)
Master (outer) case width: 450 mm
Master (outer) case gross weight: 12.2 kg
