Features
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Networking standards: IEEE 802.11ax, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate (5 GHz): 2400 Mbit/s
VLAN support: Yes
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Maximum data transfer rate: 2400 Mbit/s
5 GHz: Yes
2.4 GHz: Yes
MIMO type: Multi User MIMO
MIMO: Yes
Quality of Service (QoS) support: Yes
Design
LED indicators: Yes
Reset button: Yes
Product colour: White
Power
Power over Ethernet (PoE): Yes
Input current: 2 A
Power consumption (max): 12.8 W
DC voltage range: 12 V
Security
MAC address filtering: Yes
Security algorithms: WPA3, WPA2-Enterprise
IGMP snooping: Yes
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Management features
Web-based management: Yes
Switch type: Managed
Weight & dimensions
Depth: 160 mm
Height: 33.2 mm
Width: 160 mm
Weight: 380 g
Performance
Built-in processor: Yes
Processor frequency: 1000 MHz
Packaging data
Package height: 39 mm
Package weight: 570 g
Package width: 266 mm
Package depth: 165 mm
Packaging content
Quantity per pack: 1 pc(s)
Protocols
Management protocols: SNTP
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Antenna
Antenna direction type: Omni-directional
Antenna type: Internal
Logistics data
Harmonized System (HS) code: 85176990
Master (outer) case length: 428 mm
Master (outer) case height: 311 mm
Master (outer) case width: 353 mm
Products per master (outer) case: 20 pc(s)
Master (outer) case gross weight: 12.2 kg
