Epson DS-770 II Sheet-fed scanner 600 x 600 DPI A4 White

Design
Scanner type: Sheet-fed scanner
Display: LCD
Built-in display: Yes
Product colour: White

Power
Power supply type: AC
Power consumption (off): 0.1 W

Operational conditions
Storage relative humidity (H-H): 15 - 85%
Operating relative humidity (H-H): 15 - 80%
Operating temperature (T-T): 5 - 35 °C
Storage temperature (T-T): -25 - 60 °C

Weight & dimensions
Depth: 169 mm
Height: 176 mm
Width: 296 mm
Weight: 3.7 kg
Compatible operating systems: Citrix XenApp 5.0, Citrix XenApp 6.0, Citrix XenApp 7.6 und höher, Linux, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Mac OS X, Mac OS X 10.6.8, Windows 10, Windows 7, Windows 7, 64-Bit-Version, Windows 8, Windows 8 (32/64 Bit), Windows 8 RT, Windows 8.1, Windows 8.1 x64 Edition, Windows Server 2008 (32/64 Bit), Windows Server 2008 R2, Windows Server 2012 (64bit), Windows Server 2012 R2, Windows Vista, Windows Vista, 64-Bit-Version, Windows Server 2003 R2, Windows XP Professional x64 Edition

System requirements
Windows operating systems supported: Windows 8 x64, Windows 8, Windows Vista x64, Windows XP Professional x64, Windows 8.1 x64, Windows 10, Windows 8.1, Windows Vista, Windows 7 x64, Windows RT, Windows 7
Mac operating systems supported: Yes
Server operating systems supported: Windows Server 2008 x64, Windows Server 2003 R2, Windows Server 2012 x64, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2008
Linux operating systems supported: Yes

Performance
Daily duty cycle (max): 7000 pages
Scan file formats: TIFF, PDF, JPEG
Light source: ReadyScan LED
Scan to: E-mail, Print, Software, FTP, Network folder
Scan drivers: TWAIN, WIA, ISIS
Ultrasonic sensor: Yes

Packaging data
Package height: 285 mm
Quantity per pack: 1 pc(s)
Package width: 250 mm
Package depth: 365 mm
Package weight: 4.58 kg
Bundled software: Epson Document Capture (Mac only), Epson Document Capture Pro (Windows only), Epson Document Capture Pro Server (on free download), Epson Scan 2, Presto! BizCard 5.6

Packaging content
Cables included: AC
Drivers included: Yes
Warranty card: Yes

Ports & interfaces
USB port: Yes
USB version: 3.2 Gen 1 (3.1 Gen 1)

Other features
Image formats supported: JPEG, TIFF
Output resolutions: 75, 100, 150, 200, 240, 300, 600, 1200 dpi

Logistics data
Products per pallet (UK): 84 pc(s)
Pallet weight (UK): 0 g
Products per pallet: 63 pc(s)
Harmonized System (HS) code: 84716070
Pallet gross weight: 0 g
Country of origin: Indonesia

Input capacity
Auto document feeder (ADF) input capacity: 100 sheets
Standard input capacity: 100 sheets

Paper handling
Legal: Yes
Scanning media types supported: Plastic Card, Post Card(JPN)
Letter: Yes
ISO B-series sizes (B0...B9): B6, B5
ISO A-series sizes (A0...A9): A4, A6, A5
Auto Document Feeder (ADF) media weight: 27 - 413 g/m²
Maximum ISO A-series paper size: A4
Minimum scan area (ADF): 50.8 x 50.8 mm
Maximum scan area (ADF): 215.9 x 6096 mm

Scanning
Duplex ADF scan speed (b/w, A4): 90 ipm
Maximum scan size: 215.9 x 6096 mm
Optical scanning resolution: 600 x 600 DPI
Duplex ADF scan speed (colour, A4): 90 ipm
Duplex scanning: Yes
Colour scanning: Yes
Input greyscale depth: 10 bit
ADF scan speed (b/w, A4): 45 ppm
Output colour depth: 24 bit
Output monochrome depth: 8 bit
Input colour depth: 30 bit
Output greyscale depth: 8 bit
ADF scan speed (colour, A4): 45 ppm

Safety warning
Warnings: Do not use in damp areas., Do not open the housing of the unit to avoid electric shock., Avoid exposure to extreme temperatures.
