Features
Magnetic stripe reader: No
Print head life: 100 km
Built-in barcodes: EAN8, CODABAR (NW-7), UPC-E, Code 93, Code 39, QR Code, ITF, UPC-A, Code 128 (A/B/C), EAN13
Page description languages: ESC/POS
Cutter: Yes
Country of origin: China
Design
Product colour: Black
Built-in display: No
Power
Power source type: DC
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
DC output voltage: 24 V
Operational conditions
Operating temperature (T-T): -10 - 50 °C
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Height: 143.3 mm
Depth: 145 mm
Weight: 1.2 kg
Width: 195 mm
Network
Ethernet LAN: Yes
Wi-Fi: No
System requirements
Windows operating systems supported: Windows 10 Enterprise x64, Windows 10 x64, Windows 8 Pro x64, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 10 IoT Enterprise, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 8 x64, Windows 10 Education, Windows 7 Home Basic, Windows 7 Ultimate, Windows 11 x64, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 11, Windows 7 Ultimate x64, Windows 7 x64, Windows 10 Home, Windows 7 Starter x64, Windows 10 Pro x64, Windows 8 Enterprise, Windows 10, Windows 10 IOT Core, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 10 Education x64, Windows 11 Enterprise x64, Windows 7 Professional x64, Windows 11 Enterprise, Windows 11 Pro, Windows 10 Home x64, Windows 8, Windows 11 Home, Windows 7 Professional, Windows 7
Mac operating systems supported: Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia, Mac OS X 12.0 Monterey, Mac OS X 11.0 Big Sur
Mac compatibility: Yes
Mobile operating systems supported: Android
Linux operating systems supported: Ubuntu 12.04, Ubuntu 14.04
Packaging data
Package weight: 1.6 kg
Package depth: 230 mm
Cables included: AC, Serial, USB
Package height: 152 mm
Package width: 201 mm
Packaging content
Drivers included: Yes
AC adapter included: Yes
Quick start guide: Yes
Ports & interfaces
Standard interfaces: RJ-11
Serial interface type: RS-232
USB connector: USB Type-B
USB 2.0 ports quantity: 1
Connectivity technology: Wired
USB port: Yes
Serial interface: Yes
Printing
Print columns: 576 dots/line
Type: POS printer
Print technology: Thermal
Maximum resolution: 203 x 203 DPI
Print speed: 300 mm/sec
Logistics data
Master (outer) case gross weight: 13 kg
Master (outer) case length: 477 mm
Master (outer) case width: 425 mm
Customs product code (TARIC): 8443321000
Products per master (outer) case: 8 pc(s)
Master (outer) case height: 328 mm
Paper handling
Maximum printing width: 7.2 cm
Supported paper width: 50 - 80 mm
