Technical details
Sustainability compliance: Yes
Compliance certificates: RoHS, CE
Features
Built-in barcodes: Code 93, Code 128 (A/B/C), 2D, EAN13, UPC-A, PDF417, UPC-E, Code 39, EAN8, 1D, QR Code, ITF
Cutter: Yes
Print head life: 100 km
Autocutter durability: 1000000 million cuts
Flash memory: 4 MB
Internal memory: 8 MB
Country of origin: China
Design
Product colour: Black
Power
Power source type: DC
Operational conditions
Storage relative humidity (H-H): 0 - 93%
Operating temperature (T-T): -10 - 50 °C
Operating relative humidity (H-H): 25 - 80%
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Width: 195 mm
Weight: 1.04 kg
Height: 143.3 mm
Depth: 145 mm
Network
Wi-Fi: No
Ethernet LAN: Yes
System requirements
Windows operating systems supported: Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 7 Professional x64, Windows XP Professional x64, Windows 7 Professional, Windows 7, Windows 7 Home Basic, Windows 7 Ultimate, Windows 8 Pro x64, Windows 7 Home Premium, Windows 7 Starter, Windows 7 Home Basic x64, Windows 8 x64, Windows XP Professional, Windows XP Home, Windows 7 Starter x64, Windows 8 Enterprise, Windows 8, Windows XP Home x64, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 7 Ultimate x64, Windows 7 x64, Windows XP
Mac compatibility: Yes
Mac operating systems supported: Yes
Linux operating systems supported: Ubuntu 14.04, Ubuntu 12.04
Packaging data
Package weight: 1.61 kg
Package depth: 230 mm
Package height: 152 mm
Package width: 201 mm
Cables included: AC, RS-232, USB
Packaging content
Quick start guide: Yes
AC adapter included: Yes
Ports & interfaces
Connectivity technology: Wired
Serial interface type: RJ-11, RS-232
USB connector: USB Type-B
USB 2.0 ports quantity: 1
Serial interface: Yes
USB port: Yes
Printing
Type: POS printer
Maximum resolution: 203 x 203 DPI
Character sets: ASCII
Print technology: Thermal
Print speed: 250 mm/sec
Logistics data
Master (outer) case width: 425 mm
Master (outer) case gross weight: 13.9 kg
Products per master (outer) case: 8 pc(s)
Master (outer) case length: 477 mm
Master (outer) case height: 328 mm
Paper handling
Maximum roll diameter: 8 cm
Maximum printing width: 7.2 cm
Supported paper width: 80 mm
