Technical details
Sustainability compliance: Yes
Compliance certificates: RoHS, CE
Power
Input current: 0.4 A
Input voltage: 5 V
Power source type: USB
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Width: 146 mm
Weight: 508 g
Depth: 114 mm
Height: 184 mm
Performance
Country of origin: China
International Protection (IP) code: IP54
Protection features: Drop proof, Water resistant
Housing material: Acrylonitrile butadiene styrene (ABS)
Product colour: Black
Packaging data
Package height: 165 mm
Package width: 156 mm
Package depth: 220 mm
Package weight: 850 g
Ports & interfaces
Cable length: 1.8 m
Connectivity technology: Wired
Standard interfaces: USB
Other features
Windows operating systems supported: Windows 10 Education x64, Windows XP Home x64, Windows 10 Pro x64, Windows 10 Education, Windows XP Professional, Windows XP Home, Windows 10 Home, Windows 7 Starter x64, Windows 10 Home x64, Windows 10 Enterprise x64, Windows 10 x64, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows XP Professional x64, Windows 10, Windows 10 IOT Core, Windows 7 Enterprise, Windows 7 Ultimate x64, Windows 7 x64, Windows 7 Professional x64, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Ultimate, Windows XP, Windows 11, Windows 11 Enterprise, Windows 10 IoT Enterprise, Windows 7 Professional, Windows 7
Quick start guide: Yes
Mobile operating systems supported: Android, iOS
Linux operating systems supported: Yes
Logistics data
Master (outer) case length: 830 mm
Products per master (outer) case: 20 pc(s)
Master (outer) case width: 475 mm
Master (outer) case gross weight: 18.5 kg
Harmonized System (HS) code: 8471900090
Master (outer) case height: 360 mm
Scanning
Optical sensor resolution (W x H): 1280 x 800 pixels
Scanner resolution: 9 mm
Working distance: 70 cm
Read rate (max): 150 reads/s
Linear (1D) barcodes supported: EAN-13, EAN-8, UPC-A, Plessey, UPC-E, MSI, Code 39, Code 128, Codabar, Code 93, Interleaved 2 of 5, Pharmacode
Scanner type: 1D/2D
2D (matrix & stacked) barcodes supported: PDF417, QR Code, Data Matrix
Type: Fixed bar code reader
Trigger mode: Continuous, Manual, Auto-induction
Sensor type: LED
